Power Requirements: 14 to 18 VD CDC

Output: 4 x 14 to 18 VDC

Output Current: Combined Total from All DC Outputs2.5 A, maximum

Operating Temperature Range: 0 to 145°F (-18 to 63°C) Connector Type: BNC

RF Frequency Range: 470 to 960 MHz

Bias Voltage(s): 2x 15 VDC (150 mA, maximum)

Impedance: 50 Ohms

RF Frequency Range: 470 to 960 MHz

Output Intercept Point: 21 dBm, typical

Connector Type: BNC

Impedance: 50 Ohms

Output Connector Isolation: 30 dB, typical

Gain: Input to Any Output Port (unused ports terminated in 50 Ohms)-1 to +1 dB

Dimensions: 1.8 x 19 x 6.8" (45 x 483 x 172 mm)

Weight: 3.6 lb (1.62 kg)

1 x Shure UA844+SWB

2 x 6 ft. (ca. 1,8 m) BNC cables

10 x 22 in. (60 cm) BNC cables

4 x Locking DC power cables (for ULX4D, ULXP4)

4 x Non-locking DC power cables (for QLXD4, SLX4, BLX4R)

2 x Bulkhead adaptors

1 x Rack mount Hardware kit

1 x PS60 Power Supply

1 x Owner's Manual
